Wall Mount 6.5kW 120V Inverter with 2 x 250V 4kw Solar Inputs (modified LV6548)

Description Please note: No batteries included in this listing. We just have a very few of these in stock, Its a Modified LV6548 (called A10)  in a wall mounted package, with plug and Play battery terminals (concealed in side cover) here is a link to the manual  “All-In One-Manual” https://www.mppsolar.com/manual/ESS_LITHIUM/ESS810A-manual-20221125.pdf   battery Manual: https://www.mppsolar.com/manual/ESS_LITHIUM/lithium 4810 battery manual 20230214.pdf   6.5kw Inverter (LV6548 and 2 x 5kwh stackabale batteries, can stacked next to eachother as well as on top in a tower style – as seen in picture)     watch the video  “https://www.youtube.com/watch?v=k3yvK4qqTDw&pp=ygUhYWxsIGluIG9uZSB3aWxsIHByb3dzZSByaWNoIHNvbGFy” Some errors in Wills video. 1) You can parallel two or more units together using the same battery bank. 2) when running two units in parallel, you can parallel the batteries from each system, so you dont need to connect the same wattage panels to each unit to balance the batteries on each phase ( in fact you dont need panels on the second unit if you parallel the batteries) 3) You can parallel extra batteries ( they dont need to be the same model and type batteries, just wire them all up in parallel, 16S batteries such as SOK, EG4, Pytes, etc etc) 4) This unit will communicate with SOk and PYTES batteries without modification  (speak the same pylontech protocol) You should never touch wires without power down in any circumstance.       Pure sine wave output Off-Grid application Programmable supply priority for PV, Battery, or Grid User-adjustable battery charging current Battery independent design 6000 Cycles battery lifr, 5 yr warranty (Pylontech)   Multiple communication for USB, RS232, SNMP, Modbus, GPRS and Wi-Fi Monitoring APP (Android and iOS) for real-time status display and parameter control Built-in 2 MPPT trackers and AC/Solar charger up to 120A Compatible with utility and generator Scalable Li-Ion battery expansion SPECIFICATIONS Model: RS-A10 Maximum PV Input Power: 8000W Rated Output Power: 6500W Maximum Charging Power: 6500W PV INPUT (DC) MPPT Range @ Operating Voltage: 90 ~ 230 VDC Maximum PV Array Open Circuit Voltage: 250 VDC Maximum Solar Charge Current: 120A Number of MPP Trackers / Maximum Input Current: 2 / 2 x 18 A AC INPUT Acceptable Input Voltage Range: 90-140 VAC (For Computers) 80-140 VAC (For Home Appliances) Maximum AC Input Current: 60A BATTERY MODE OUTPUT Nominal Output Voltage: 120 VAC Maximum Conversion Efficiency (DC/AC): 93%
